Victron Energy BlueSolar PWM-Pro 12/24V-10A
Only 1 piece in stock at supplier
Nominal current3
Product details
The Victron BlueSolar PWM-PRO 10A (MPN SCC010010010) is a solid entry-level device in solar technology and already integrates several professional features. It supports both the 12V and 24V battery voltage ranges, making it very versatile. The BlueSolar series from Victron offers more comfort and configuration options compared to the PWM-Light series. Additionally, an optional remote display is available, which allows you to monitor and configure the controller.
The free programming of all important control parameters is done via the Remote Panel or a USB-Link cable with PC software. Through the optional Remote Panel, almost all relevant settings, such as charging voltage, can be customized, a feature typically found only in higher-end models. Programmable parameters include battery type-specific charging and float voltages, as well as the cut-off and turn-on thresholds for the load output.
The Remote Panel is an optional accessory and is not included with the controller. For detailed programming options, please refer to the manual. A more affordable version of the controller's remote with similar, if not higher, user comfort is offered by Victron's optional USB-Link cable.
Nominal voltage | 24 V |
Nominal current | 10 A |
Safety function | Reverse polarity, Short circuit, Undertemperature |
Item number | 22985928 |
Manufacturer | Victron Energy |
Category | Charge controller |
Manufacturer No. | SCC010010010 |
Release date | 4/11/2022 |
Colour | Grey |
Exact colour description | Grey |
Nominal voltage | 24 V |
Nominal current | 10 A |
Safety function | Reverse polarity, Short circuit, Undertemperature |
Display type | Analogue |
Protection type (IP code) | IP30 |
Country of origin | China |
CO₂ emissions | 19,87 kg |
Climate contribution | EUR 0,50 |
Items per sales unit | 1x |
Length | 7 cm |
Width | 13.80 cm |
Height | 13.80 cm |
Weight | 300 g |
Product Safety |
Length | 15.50 cm |
Width | 8.60 cm |
Height | 5 cm |
Weight | 177 g |
