Motor protection system: SIMOCODE Pro C
Motor protection components: Basic unit
Number of inputs: 4
Output: 3
Detection type: Thermistor
Supply voltage: 24 Vdc
Total length: 111 mm
Total width: 45 mm
Total depth: 95 mm
Operating temperature min: -25°C
Operating temperature max: +60°C

The SIMOCODE Pro C is a practical and economical motor management system. It is a flexible, modular system that optimizes the connection between I/O and the motor system, increases system availability, and enables significant savings in system start-up, operation, and maintenance. When installed in a cabinet, it serves as the intelligent interface between the higher automation system and the motor feeder, including multifunctional solid-state relay motor protection that operates independently of the automation system. It features flexible software for motor control, detailed operation, maintenance, and diagnostic data, and open communication through PROFIBUS DP, the standard for fieldbus systems.

The SIMOCODE Pro C system is used for direct and reversing motor starters, actuating a circuit breaker with up to 4 binary inputs, up to 3 monostable relay outputs, and a thermistor connection (binary PTC). The base unit is available in two versions for the following supply voltages: 24 Vdc and 110 to 240 Vac/dc.

Inputs: 4 binary inputs with internal supply of 24 Vdc
Outputs: 3 (2+1) monostable relay outputs, thermistor connection for binary PTC
PROFIBUS interface: 9-pin sub-D or terminal block
Supply voltage connection: 24 Vdc or 110 to 240 Vac/dc
Test/reset button: 3 LEDs
System interfaces: 2 for connection of a current measuring module and a control panel

The base unit is suitable for standard rail mounting or, with additional plug-in mounting lugs, for mounting on a mounting plate.
