1. Moxa Profibus To 4-Ch Hard Gateway
2. Moxa EDR-810
The EDR-810 is a highly integrated industrial multiport security router with firewall/NAT/VPN and managed layer 2 switch functions. Designed for Ethernet-based security applications in critical remote control or monitoring networks, it provides an electronic security perimeter to protect critical cyber assets, including pump-and-treat systems in water stations, DCS systems in oil and gas applications. and PLC/SCADA systems in factory automation. The EDR-810 series includes the following cyber security features:
The EDR-810's "WAN Routing Quick Setup" provides users with an easy way to set up WAN and LAN ports to create a routing function in four steps. In addition, the EDR-810's "Quick Automation Profile" provides engineers with an easy way to configure the firewall filter function with common automation protocols, including EtherNet/IP, Modbus TCP, EtherCAT, FOUNDATION Fieldbus and PROFINET. Users can easily create a secure Ethernet network with a single click via a user-friendly web interface, and the EDR-810 is capable of comprehensive Modbus TCP packet inspection. Wide temperature range models are also available that operate reliably in hazardous environments from -40 to 75 °C.
3. Moxa PT-508-SS-SC-HV
The Moxa PT-508-SS-LC-HV is an industrial-grade Ethernet switch designed for demanding environments that require reliable network connections. This 8-port managed switch features a stainless steel construction that enhances durability and corrosion resistance, making it ideal for industrial automation, transportation, and energy applications. With an operating temperature range of -40 °C to 75 °C, the device ensures stable performance under extreme conditions. The switch supports Power over Ethernet Plus (PoE+) functionality, delivering up to 30 W per port for connected devices such as IP cameras, Wi-Fi access points, and industrial sensors. It includes LC fiber optic ports for long-distance connections and supports various network protocols including Ethernet/IP, Modbus TCP, and PROFINET for seamless integration into industrial control systems. The compact design measures 53 mm in height, 135 mm in width, and 105 mm in depth, with a weight of approximately 1.2 kg. Advanced management features include VLAN support, Quality of Service (QoS) prioritization, port mirroring, and SNMP monitoring for comprehensive network control. The switch offers redundant power supply with an operating voltage range of 12 to 48 VDC and includes built-in surge protection for increased reliability. With its industrial certifications and robust construction, this Ethernet switch provides reliable network solutions for critical infrastructure applications where continuous operation is essential.
4. Moxa 45MR-2601 - Module for the ioThinx 4500 Series, 16 DOs, 24 VDC, source, -20 to 60C operating
The 45MR-2601 module is part of Moxa's ioThinx 4500 series and provides a reliable solution for digital outputs in industrial applications. With 16 digital output channels requiring a supply voltage of 24 VDC, this module is ideal for controlling and automating processes. It is designed to operate in a temperature range of -20 to 60 °C, making it suitable for various environments. Installation is straightforward on a DIN rail, and connections are made via spring Euroblock terminals. The module supports both standard digital outputs and pulse outputs for the first four channels, offering additional flexibility. With high insulation of up to 3 kVDC, it is also well protected against electrical disturbances.
- Operating temperature range of -20 to 60 °C for versatile applications
- Supports pulse outputs for the first four channels
- High insulation of 3 kVDC for increased safety
- Easy mounting on DIN rail for hassle-free installation
- Certified according to various standards for electromagnetic compatibility and safety.
Network adapters
EUR219,–
Moxa 45MR-2601 - Module for the ioThinx 4500 Series, 16 DOs, 24 VDC, source, -20 to 60C operating
5. Moxa UPort 1110 USB Serial Converter Cable
The USB-to-Serial Converter UPort 1110 is a convenient addition for laptops without a serial port. It converts USB to RS-232 and is compatible with both new and older RS-232 devices.
Supported operating systems: Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1 (x86/x64), Windows 2012 (x64), Windows Embedded CE 5.0/6.0.
6. Moxa 45MR-3800-T - Module for the ioThinx 4500 Series, 8 AIs, 0 to 20 mA or 4 to 20 mA, -40 to 75C
Module for the ioThinx 4500 series, featuring 8 analogue inputs with a range of 0 to 20 mA or 4 to 20 mA, and an operating temperature of -40 to 75°C.
Input/output interface:
- Analogue input channels: 8
- Isolation: 3 kV DC or 2 kV RMS
Analogue inputs:
- Connection: Spring-Euroblock-Terminal
- I/O mode: Current
- I/O type: Differential
- Resolution: 16 bit
- Input range:
- 0 to 20 mA
- 4 to 20 mA
- 4 to 20 mA (with burn-out detection)
- Accuracy:
- ±0.1% FSR @ 25°C
- ±0.3% FSR @ -40 and 75°C
- Sampling rate:
- All channels: 100 samples/sec
- Per channel: 12.5 samples/sec
- Single channel: 100 samples/sec
- Input impedance: 120 Ohm
Power consumption:
- System power: 197.3 mA @ 3.3 V DC
Physical characteristics:
- Housing: Plastic
- Dimensions: 19.5 x 99 x 60.5 mm (0.77 x 3.90 x 2.38 in)
- Weight: 79.8 g (0.176 lb)
- Installation: DIN rail mounting
- Stripping length: I/O cable, 9 to 10 mm
- Wiring: 18 to 24 AWG
Ambient conditions:
- Operating temperature: -40 to 75°C (-40 to 167°F)
- Storage temperature (including packaging): -40 to 85°C (-40 to 185°F)
- Relative humidity: 5 to 95% (non-condensing)
- Altitude: Up to 4000 metres
Standards and certifications:
- EMC: EN 55032/35
- EMI: CISPR 32, FCC Part 15B Class A
- EMS:
- IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
- IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
- IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
- IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
- IEC 61000-4-6 CS: 3 V
- IEC 61000-4-8 PFMF
- Shock: IEC 60068-2-27
- Vibration: IEC 60068-2-6
- Safety: UL 61010-2-201
- Hazardous areas: ATEX, Class I Division 2
Declaration:
- Environmentally friendly product: RoHS, CRoHS, WEEE
MTBF:
- Time: 2,085,426 hours
- Standards: Telcordia SR332.
Network adapters
EUR609,–
Moxa 45MR-3800-T - Module for the ioThinx 4500 Series, 8 AIs, 0 to 20 mA or 4 to 20 mA, -40 to 75C
7. Moxa 45MR-4420-T - Module for the ioThinx 4500 Series, 4 AOs, 0 to 10 V or 0 to 20 mA or 4 to 20 mA
Moxa's advanced controllers and I/O products simplify the realization of complex IIoT applications such as energy management, factory machine management, transportation management, and remote asset management through expandable communication and high-performance data acquisition and control capabilities. Use the ioThinx 4500 Series Power Calculator to determine how many power modules are needed for your application.
Module for the ioThinx 4500 Series, 4 AOs, 0 to 10 V or 0 to 20 mA or 4 to 20 mA, -40 to 75°C operating temperature.
Input/Output Interface
- Analog Output Channels: 4
- Isolation: 3 kVDC or 2 kVrms
- Analog Outputs:
- Connector: Spring-type Euroblock terminal
- I/O Mode: Voltage/Current
- Output Range: 0 to 10 VDC, 0 to 20 mA, 4 to 20 mA
- Resolution: 12-bit
- Accuracy:
- ±0.1% FSR @ 25°C
- ±0.3% FSR @ -40 to 75°C
- Load (Current Mode):
- Internal power: 500 ohms (max.)
- Load (Voltage Mode): 1000 ohms (min.)
- Power Consumption:
- System Power: 44 mA @ 3.3 VDC
- Field Power:
- 220.2 mA @ 12 VDC
- 122.3 mA @ 24 VDC
Physical Characteristics
- Housing: Plastic
- Dimensions: 19.5 x 99 x 60.5 mm (0.77 x 3.90 x 2.38 in)
- Weight: 79 g (0.175 lb)
- Installation: DIN-rail mounting
- Strip Length: I/O cable, 9 to 10 mm
- Wiring: 18 to 24 AWG
Environmental Limits
- Operating Temperature: -40 to 75°C (-40 to 167°F)
- Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
- Ambient Relative Humidity: 5 to 95% (non-condensing)
- Altitude: Up to 4000 meters
Standards and Certifications
- EMC: EN 55032/35
- EMI: CISPR 32, FCC Part 15B Class A
- EMS:
- IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
- IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
- IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
- IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
- IEC 61000-4-6 CS: 3 V
- IEC 61000-4-8 PFMF
- Shock: IEC 60068-2-27
- Vibration: IEC 60068-2-6
- Safety: UL 61010-2-201.
Network adapters
EUR704,22
Moxa 45MR-4420-T - Module for the ioThinx 4500 Series, 4 AOs, 0 to 10 V or 0 to 20 mA or 4 to 20 mA
8. Moxa A52-DB25F W/O ADAPTER - RS-232422485 converter with DB25F cable
The A52-DB25F W/O Adapter from Moxa is a versatile RS-232/422/485 converter equipped with a DB25F cable. This device enables reliable serial communication across various standards and is ideal for applications that require robust data transmission. With two ports, the converter offers flexibility in connecting devices. The Automatic Data Direction Control (ADDC) ensures efficient handling of data streams, while flow control via RTS/CTS guarantees stable communication. The converter is designed for desktop use and features a compact, lightweight design that allows for easy integration into existing systems. Additionally, it is suitable for operation in a wide temperature range, making it a reliable choice for various environments.
- Supports serial standards RS-232, RS-422, and RS-485
- Automatic Data Direction Control (ADDC) for efficient data transmission
- Flow control via RTS/CTS to ensure stable connections
- Robust plastic housing with IP30 protection rating
- Operating temperature range of 0 to 55°C for versatile applications.
Network adapters
EUR75,90
Moxa A52-DB25F W/O ADAPTER - RS-232422485 converter with DB25F cable
RJ45, RS-232, RS-422/485
9. Moxa 45MR-3810 - Module for the ioThinx 4500 Series, 8 AIs, -10 to 10 V or 0 to 10 V, -20 to 60C
The 45MR-3810 module from Moxa is a highly advanced device specifically designed for the ioThinx 4500 series. It features eight analog inputs that support voltage ranges of -10 to 10 V as well as 0 to 10 V. With an operating temperature range of -20 to 60 °C, this module is suitable for a variety of industrial applications. Its robust construction and the option for DIN rail mounting make it a flexible solution for integration into existing systems. The module is equipped with a high accuracy of ±0.1 % FSR at 25 °C and offers a sampling rate of up to 100 samples per second for all channels. Additionally, the isolation of up to 3 kV DC ensures safe usage in demanding environments. The use of spring Euroblock terminals allows for easy and reliable wiring.
- Operating temperature range of -20 to 60 °C for versatile applications
- High accuracy of ±0.1 % FSR at 25 °C
- Sampling rate of up to 100 samples per second for all channels
- Isolation of up to 3 kV DC for enhanced safety
- Easy wiring through spring Euroblock terminals.
Network adapters
EUR469,–
Moxa 45MR-3810 - Module for the ioThinx 4500 Series, 8 AIs, -10 to 10 V or 0 to 10 V, -20 to 60C
10. Moxa ABC-01-P-M12-CT-T - Configuration backup and restoration tool with M12 connector for s ToughNet
The ABC-01-P-M12 is designed for system backup and restoration to enhance maintenance efficiency and reduce system downtime in railway applications, including rolling stock and wayside installations. The ABC-01-P-M12 Automatic Backup Configurator tool can be used to save and load the configuration of Moxa’s ToughNet managed Ethernet switches and wireless access points, bridges, and clients through the RS-232 console port. The ABC-01-P-M12 can be continuously plugged into Moxa’s Ethernet switches and wireless access points, bridges, and clients while the devices are operating, making it easier to back up system parameters and manage configurations. With the ABC-01-P-M12, you can quickly configure a replacement switch of the same model.
The ABC-01-P-M12 is compliant with mandatory sections of EN 50155, covering operating temperature, surge, ESD, and vibration, as well as conformal coating, making it suitable for a variety of industrial applications.
Interface
Connectors: RS-232 M12 port
Basic Operation
Storage Capacity: 64 KB
Power Requirements
Input Voltage: 3 to 5 VDC, power input via RS-232 RTS
Physical Characteristics
Housing: Aluminum
IP Rating: IP67 protection
Dimensions: 55 mm x Ø20 mm (2.17 in x Ø0.79 in)
Weight: 35 g (0.08 lb)
Environmental Limits
Operating Temperature: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95 % (non-condensing)
Altitude: 2000 m
Standards and Certifications
EMI: CISPR 32, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 20 V/m (80 MHz to 1 GHz)
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Rail Traffic: (for plug-in installations)
EN 50155, EN 50121-4, EN 45545-2
This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard.
Network adapters
EUR239,–
Moxa ABC-01-P-M12-CT-T - Configuration backup and restoration tool with M12 connector for s ToughNet
RS-232
