Hager surge arrester SPC203N

Manufacturer: Hager
Description: Surge arrester T3 1P+N Uc 264V
Type: SPC203N
Rated voltage AC: 240 V
Rated voltage DC: 240 V
Maximum continuous voltage AC: 264 V
Maximum continuous voltage DC: 240 V
Rated load current: 26 A
Rated leakage current (8/20) (L-N): 10 kA
Total leakage current (8/20) (L+N-PE): 10 kA
Total leakage current (8/20) (L1+L2+L3+N-PE): 10 kA
Protection level: 1.25 kV
Protection level L-N: 1.25 kV
Protection level L-PE/N-PE: 1.4 kV
Max. overcurrent protection device stub wiring (fuse): 32 A
Max. overcurrent protection device V-wiring: 10 A
Overcurrent protection device V-wiring (fuse): 25 A
No. of poles: 2
Mounting type: Top-hat rail TH35
Max. conductor cross-section rigid (single): 4 mm²
Max. conductor cross-section rigid (solid/multi-wire): 4 mm²
Max. conductor cross-section flexible (fine-stranded): 5 mm
Max. conductor cross-section flexible (flexible): 2.5 mm²
With remote signalling contact: Yes
Signalling on device: Optical
Test class type 3: Yes
Protection class (IP): IP20

Further details: Surge arrester T3 1P+N Uc 264V In 5kA Up 1.25kV contact. Surge arrester type 2/3, consisting of protective plug and base element for single-phase power supply systems (AC/DC). Rail-mountable device with screw connection technology and individual labelling area on the front. Integrated, powerful disconnect for safe behaviour in case of overload. Optical red/green status display and potential-free remote signalling contact for fault signalling. Protective plugs are protected against mismating by mechanical coding and can be plugged and unplugged without tools.
