Airplane Piston Compressor 221 OF E Handy Silence

• Small portable compressor with a compact design
• Very quiet operation, making it extremely silent
• Oil-free piston compressor: no oil changes required and no oil in the condensate for optimal working quality
• Air pressure regulator for stepless adjustment of the desired working pressure
• High-quality pressure switch
• Electric motor equipped with motor protection switch
• Fully automatic on/off operation
• One pressure gauge for displaying tank and working pressure
• Powder-coated air tank
• Vibration-dampening suction cups

Technical Data

General Information
Air outlet: ¼"

Dimensions and Weights
Length (Product) approx.: 370 mm
Width/Depth (Product) approx.: 270 mm
Height (Product) approx.: 530 mm
Weight (net) approx.: 16 kg

Electrical Data
Supply voltage: 230 V
Mains frequency: 50 Hz
Output power: 1.0 kW
Input power: 1.1 kW
Drive power: 0.75 kW
Drive efficiency: 70%

Noise Emission
Sound power level Lp: 61 dB(A)

Compressor
Compressor system: WDS
Oil-free / oil-lubricated: Oil-free
Suction capacity approx.: 200 l/min
Filling capacity approx.: 90 l/min
Explanation of filling capacity: at 6 bar working pressure
Number of cylinders: 2
Number of compression stages: 1
Compressor speed: 2850 min¯¹
Piston stroke: 11.2 mm
Piston diameter: 63.7 mm

Air Tank
Maximum pressure: 8 bar
Tank capacity: 6 liters
Tank orientation: Horizontal
Tank surface: powder-coated.
