WAGO GmbH & Co. KG Sensor/Actuator Distribution Box 757-483/000-005

Manufacturer: WAGO GmbH & Co. KG
Description: Sensor/Actuator Distribution Box 8-fold, 3-pole, 5 m
Type: 757-483/000-005
Cable outer diameter for cable gland: 7.4 mm
Length of pre-assembled cable: 5 m
Configurable cable length: yes
Number of sensor/actuator slots: 8
Number of channels per slot: 8
Design of outlets for sensor/actuator cables: M8
Number of poles for sensor/actuator slots: 3
Rated voltage: 32 V
Degree of pollution: 3
Operating voltage: 10..30 V
Max. current load per I/O signal: 2 A
Max. current load per connection socket: 6 A
Material of contact base: Brass
Material of contact coating: Gold
Material of insulating body: Polyamide (PA)
Threaded sockets of sensor/actuator slots: M8
With LED display: yes
With potential separation: no
Connection for NPN sensors: no
Cable carrier suitability of fixed cable version: yes
Material of housing: Plastic
Housing color: other
Operating temperature: -25..80 °C
Protection class (IP): IP68
Explosion protection category for gas: none
Explosion protection category for dust: none
Width: 30 mm
Height: 20 mm
Depth: 152 mm

WAGO GmbH & Co. KG Sensor/Actuator Distribution Box 757-483/000-005: additional details M8 Sensor/Actuator Box 8-fold 3-pole 5 m, EAN: 4044918978637.
