WAGO GmbH & Co. KG male connector 734-304/019-000

Manufacturer: WAGO GmbH & Co. KG
Designation: Male connector 4-pole
Type: 734-304/019-000
Connection type: PCB to PCB
Contact design: Pin
Number of poles: 4
Number of rows of plug-in contacts: 1
Contact pitch: 3.5 mm
Terminal pitch: 3.5 mm
Angle contact/conductor connection: 180° (horizontal)
Rated current: 10 A
Rated voltage: 160 V
Rated impulse voltage: 2.5 kV
Overvoltage category: III
Pollution degree: 2
Connectable conductor cross-section flexible without ferrule: 0.8 to 1.5 mm²
Connectable fine-stranded conductor cross-section with ferrule: 0.25 to 1.5 mm²
Connectable solid conductor cross-section: 0.08 to 1.5 mm²
Connectable conductor cross-section stranded: 0.08 to 1.5 mm²
Electrical connection type: Spring-loaded connection
Connectable cable type: Round cable
Material of contact coating: Tin
Material of contact: Other copper alloys
Material of insulating body: Thermoplastic
Material of housing: Plastic
Coating of housing: Uncoated
Housing colour: Grey
Flammability class of insulating material according to UL 94: V0
With protective conductor: No
Operating temperature: -60 to 100 °C
Protection class (IP), mounted: IP10

WAGO GmbH & Co. KG male connector 734-304/019-000: further details
1-conductor male connector CAGE CLAMP® 1.5 mm²
Spacing: 3.5 mm
4-pole
100% mismating protected
Fixing flange: 1.50 mm²
Light grey.
