Schneider Electric Push Button XB5AA21

Manufacturer: Schneider Electric
Designation: Flat push button, black, 1S
Type: XB5AA21
Number of control points: 1
Button shape: flat
Button color: black
Lens shape: round
Hole diameter: 22.5 mm
Suitable for lighting: no
Latching switch function: no
Momentary: yes
Number of contacts as normally open: 1
Type of electrical connection: screw terminal
With front ring: yes
Material of front ring: plastic
Front ring color: black
Protection class (IP): IP66
Protection class (NEMA): 4X

Schneider Electric Push Button XB5AA21: additional details
The Harmony XB5 series made of plastic offers a wide range of 22 mm complete devices such as push buttons, indicator lights, and selector switches, including emergency stop buttons. Additionally, due to the modular design of the devices, all components can also be purchased as individual elements, and they can optionally be used for 30 mm mounting dimensions. Due to their quality, flexibility, and extreme robustness (protection classes up to IP69K), these devices are ideal for most applications in industry and buildings. Installed in a 22 mm hole, the device is connected via screw terminals on the back of the product. This push button features 1 normally open contact and is unmarked. It is suitable for international use due to the numerous existing product standards and certifications. Thanks to the Green Premium environmental label, you can obtain detailed information on material contents, environmental impacts, and circular economy, which support your sustainability goals.
