Supply voltage: 24 to 240 V AC/DC
Number of channels: 2
Auxiliary contact: 1
Safety contacts: 3
Range: PNOZ X
Reset type: Automatic, manual
Connection type: Screw fastening
Width: 45 mm

CE, cULus approval, TÜV, KOSHA, CCC. The PNOZ X3 series of safety relays from PILZ introduces a safety-related interruption into your circuit, with primary applications typically found in potentially hazardous environments where rapid power shutdown is required. This is particularly useful in automated environments with high foot traffic, such as factories and warehouses.

Features and benefits:

• LED status indicators to assist in switching the channel status between 1 or 2 signals and to monitor the supply voltage
• Semiconductor output signals: Switching status channel 1/2
• 3 safety contacts, 1 auxiliary contact
• Multiple connection outputs and status indicators
• The opening and closing of the safety relays are automatically checked with each on/off cycle
• A monitored manual reset is available in this device
• Standard for DIN rail mounting

Safety features:

• The circuit is redundant and equipped with integrated self-monitoring
• Reliable X3 functionality ensures that your safety function remains effective even in the event of component failure
• The transformer is short-circuit proof, and a safety module is used with a DC power supply

Applications:

• Emergency stop buttons
• Safety door guards
• Reset buttons
• Light curtains

Safety technical parameters:

• EN 60204-1
• EN (IEC) 62061
• EN ISO 13849-1
• VDE 0113-1
• EN 60947-5-1.
