ēlo ET1517L TOUCH DISPLAY

1024 x 768 pixels, 15"
Price in EUR including VAT
Delivered between Tue, 20/5 and Sat, 24/5
5 items in stock at supplier

Product details

The 1517L Zero-Bezel Touch Monitor is designed with a robust industrial design "built for touch" for continuous use in public environments. It offers style and performance with a variety of features for enhanced functionality. It is well-suited for public facilities where Point-of-Sale (POS), Point-of-Information (POI), Point-of-Service, interactive digital signage at shelf and counter levels, customer engagement systems, and kiosk information systems can be found. The optional 3-track magnetic stripe reader (MSR), which can be programmed for either HID or keyboard emulation, is easily installed by the user and provides a sleek, integrated solution that requires no external mounts or attachments. The 1517L features two leading zero-bezel touchscreen technologies for a smooth, easy-to-clean surface: the AccuTouch five-wire resistive technology, which is most commonly used for retail applications and is proven to withstand liquid spills, food, and grease; and the iTouch pure glass surface wave technology for the highest optical quality in dry retail and hospitality applications. The Elo 1517L is a 15" (38.1 cm) LCD touchscreen monitor with a 4:3 aspect ratio, a response time of 25 ms, a resolution of 1024 x 768 (XGA-2), an adjustable display angle, 16.2 million colors, a contrast ratio of 700:1, a brightness of 250 cd/m², and LED backlighting.

Key specifications

Monitor type
PC Monitor
Display resolution
XGA
Screen technology
LED
Refresh rate
60 Hz
Video connections
VGA (1x)
USB ports
USB-A
Monitor equipment
Touch screen
Documents
Item number
10127608

General information

Manufacturer
ēlo
Category
Monitor
Manufacturer no.
E344758
Release date
27/12/2013
External links

Colour

Colour
Black
Exact colour description
Black

Display properties

Monitor type
PC Monitor
Display size (inches)
15"
Screen size (cm)
38.10 cm
Image resolution
1024 x 768 pixels
Display resolution
XGA
Screen technology
LED
Panel technology
TN
Refresh rate
60 Hz
Aspect ratio
4:3
Screen surface
Anti-glare
Contrast ratio
800 :1
Response time (grey-to-grey)
23 ms
Brightness
270 cd/m²
Colour depth
8 bits
Viewing angle (H)
160°
Viewing angle (V)
150°

Features + Functions

Monitor equipment
Touch screen
Connectivity
SerialUSB
Touch
Single-touch

Mounting + Ergonomics

Adjustability
Not movable
VESA wall mount
75 x 75 mm

Connections

Video connections
VGA (1x)
USB ports
USB-A
Exact USB ports
USB-A 2.0 (1x)

Power supply

Power consumption
10.50 W
Power consumption (standby)
1.20 W
Power consumption (Off)
0.40 W
Energy consumption per year
10 kWh

Energy declaration

Energy efficiency class
E

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
ACUSB Type-A to USB Type-BVGA

Product dimensions

Width
358 mm
Length
197 mm
Height
319 mm
Weight
4.30 kg

Package dimensions

Length
45 cm
Width
23 cm
Height
40.50 cm
Weight
6.26 kg
