ASUS PRO WS X299 SAGE II

LGA 2066, Intel X299, SSI CEB
Currently out of stock

Product details

Professional motherboard for servers. LGA 2066 socket with X299 chipset and SSI CEB form factor. 7 PCI-Express 3.0 x16 slots. Memory: DIMM DDR4 (up to 256 GB, 4266 MHz). Number of memory slots: 8. Wi-Fi: No. RJ-45 ports: 2, RJ-45 speed: 2.5 Gbit/s. SATA-III ports: 8. M.2 ports: 2. The motherboard features two M.2 interfaces for fast M.2 SSDs. This interface is particularly recommended for the drive containing the operating system or frequently used applications, speeding up the entire PC and productivity applications.

Energy Processing Unit. Actively save power with the EPU (Energy Processing Unit): The EPU regulates the power consumption of your components, allowing for a reduction of up to 12 W for the CPU, for example. The best part is that this process happens automatically. Your savings are maximized through the Away mode, where unused I/O controllers are turned off in your absence and graphics cards are put into power-saving mode.

ASUS Control Center. This workstation motherboard features the ASUS Control Center (ACC), a centralized and integrated IT management platform for monitoring and controlling ASUS products, including servers, workstations, and digital signage. ACC enables BIOS updates via remote access, monitoring multiple systems through mobile devices, as well as software updates and software dispatching with just one click. These features simplify server management for any IT infrastructure.

Key specifications

Processor family
Core X
Memory type
DDR4-RAM
Number of memory modules (RAM)
8 x
Internal connection options
M.2 PCI/SATA Combo (1x)M.2 PCIe (1x)S-ATA III (8x)
Mainboard features
Clear CMOS ButtonPower-On Button
Item number
15719505

General information

Manufacturer
ASUS
Category
Motherboards
Manufacturer no.
90SW00U0-M0EAY0
Release date
10/1/2022
External links

Motherboard properties

Form factor
SSI CEB
Socket
LGA 2066
Chipset
Intel X299
Mainboard features
Clear CMOS ButtonPower-On Button
Operating system compatibility
Windows

Processor

Processor family
Core X

Memory

Memory form factor
DIMM
Number of pins
184 x
Number of memory modules (RAM)
8 x
Max. memory (RAM)
256 GB
Memory chip
DDR4-4266
Supported memory speed
2400 MHz2666 MHz2933 MHz4000 MHz
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
Thunderbolt 3
Multi-GPU technology
AMD 4-Way CrossFireXNVIDIA Quad SLI

Network

Network connections
RJ45 2.5 Gigabit Ethernet (2x)
Ethernet controller brand
Intel
Ethernet controller
Intel I225-LM
Max. port speed
2.50 Gbit/s

Audio

Chip
Realtek ALC S1220A
Audio channel
7.1 Channel
Audio Connections
Jack 3.5mm (5x)

Data storage

RAID configuration
01105

Internal interfaces

Internal connection options
M.2 PCI/SATA Combo (1x)M.2 PCIe (1x)S-ATA III (8x)
Expansion slot
PCI Express x16 (7x)
Number of fan connector
3

Further connections

USB ports
USB-AUSB-C

Power supply

Power connectors
24-pin ATX6-pin PCI-E8-pin ATX 12V

Sustainability

Manufacturer commitment
RE100SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer ASUS fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
1x serial control panel8x Serial ATA cable

Product dimensions

Length
267 mm
Width
305 mm
Height
287 mm
Weight
2300 g

Package dimensions

Length
34 cm
Width
29 cm
Height
8 cm
Weight
2.33 kg
