AsRock NUC BOX-J6412
Intel Celeron J64127 items in stock at supplier
Product details
The AsRock NUC BOX-J6412 is a compact barebone PC designed for versatile applications. With a micro-tower case, it offers an efficient solution for users seeking a powerful yet space-saving computer option. Equipped with an Intel Celeron J6412 processor, which has a base clock speed of 2.0 GHz and can reach a turbo boost of up to 2.6 GHz, this barebone PC delivers smooth performance for everyday tasks. The NUC BOX-J6412 supports up to 32 GB of DDR4 RAM and features two slots for SSDs, allowing for flexible storage expansion. With two Gigabit LAN ports and integrated Wi-Fi connectivity, the NUC BOX-J6412 is ideal for network-intensive applications. The active cooling system ensures efficient heat dissipation, while the compact form factor allows for easy integration into various environments.
- Supports up to 32 GB of DDR4 RAM for high performance
- Two Gigabit LAN ports for fast network connections
- Active cooling for efficient heat dissipation
- VESA mounting kit included for flexible mounting options
- Maximum support for two monitors for an extended workspace.
Number of processor cores | 4 -Core |
Graphics card model | Intel UHD Graphics |
Internal connection options | M.2 (1x), S-ATA (1x) |
Network connections | RJ45 (2x) |
Video connections | DisplayPort (1x), HDMI (1x) |
Memory type | DDR4-RAM |
USB ports | USB-A, USB-C |
Item number | 23768913 |
Manufacturer | AsRock |
Category | Barebones |
Manufacturer no. | 90PXG8M0-P0EAY100 |
Release date | 3/3/2022 |
External links |
Design | Small Form |
Processor type | Intel Celeron J6412 |
Clock frequency | 2 GHz |
Number of processors | 1 x |
Number of processor cores | 4 -Core |
Max. turbo clock rate | 2.60 GHz |
Processor properties | Onboard processor |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260 x |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 32 GB |
Graphics card model | Intel UHD Graphics |
Max. connected monitors | 2 x |
Internal connection options | M.2 (1x), S-ATA (1x) |
Data storage controller | Intel SoC |
USB ports | USB-A, USB-C |
Exact USB ports | USB-A 2.0 (1x), USB-A 3.2 Gen 2 (2x), USB-C 3.2 Gen 2 (2x) |
Network connections | RJ45 (2x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac |
Bluetooth version | 4.2 |
Video connections | DisplayPort (1x), HDMI (1x) |
Audio outputs | 6.3mm stereo (1x) |
Power | 65 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | VESA mounting kit, screw set |
Weight | 1270 g |
Width | 110 mm |
Length | 117.50 mm |
Height | 47.85 mm |
Length | 23 cm |
Width | 14.80 cm |
Height | 11.90 cm |
Weight | 1.27 kg |
